Expressive seriesFreezerRVF497790

Vario cooling Expressive series freezer 36''
RVF497790

1 / 0
Photo Nr. 1 of the product RVF497790
Photo Nr. 2 of the product RVF497790
Photo Nr. 3 of the product RVF497790
Photo Nr. 4 of the product RVF497790
Photo Nr. 5 of the product RVF497790
Photo Nr. 6 of the product RVF497790

Vario cooling Expressive series freezer 36''
RVF497790

Find a showroom or a local dealer

Vario cooling Expressive series freezer 36''
RVF497790

Find a showroom or a local dealer

Additional information

Dark brushed stainless steel interior, refined with solid anthracite aluminium elements
Warm white and glare-free LED light concept for optimal food presentation in all compartments
Opening assist for door with two options:
1. Push-to-open function for integration into handleless furniture front
2. Pull-to-open function to facilitate opening the door using a handle
The drawers in the RVC and RVF models are positioned at the same height. With side-by-side installation, the safety glass shelves and door racks can be aligned on the same level.
Flexible positioning of shelves and door racks through hidden rail system
Flat dark brushed stainless steel inner door
Total volume: 22.3 cu. ft.
ENERGY STAR certified.
Opening assist for door.
Cushioned door closing system.
Light and display response to drawer interaction.
Automatic brightness adjustment based on ambient illumination.
Hidden touch display.
Dynamic cold air distribution with Multi-Flow Air System.
Automatic defrosting with defrost
water evaporation.
Sabbath mode certified by Star-K.
When rest mode is active, the appliance can only be opened using a handle.
Open-door and malfunction warning system.
Remote control and monitoring.
Software updates.
No-frost technology with fast freezing at -15 °F (-30 °C).
4-star freezer compartment.
Temperature adjustable from -11 °F to 3 °F (-24 °C to -16 °C).
Freezer burn protection.
Oxidation protection.
Warm-white, glare-free LED lighting (3000 K) within freezer compartment.
3 aluminum-framed safety glass shelves, individually adjustable in height.
Flexible positioning of door racks through hidden rail system.
3 height-adjustable door racks.
3 fully extendable drawers, with cushioned closing system.
Hidden in one drawer for optimised usable space.
With fixed water connection (inlet).
Ice maker can be switched off independently.
Active charcoal water filter for water inlet, integrated in ventilation grill area.
Ice cube production: approx. 5.2 lb/24 h.
Removable ice storage container with approx. 6.6 lb capacity.
Integrated, easy accessible ice cube scoop.
Saturation indicator shown in touch display.
Energy consumption 536 kWh/year.
Noise level 39 dB (re 1 pW).
Flat hinge.
Door hinge left, reversible.
Door opening angle of 115°, fixable at 90°.
Max. door panel weight 84 lbs (38 kg).
Shut-off valve for water connection must be planned next to the appliance and always be accessible.
If the water pressure exceeds 116 psi, connect pressure relief valve between water tap and hose set.
Total rating 1.079 kWh/24 h.
Total Amps: 10 A.
Connecting cable 118" (3.0 m), detachable.
Cold water connection required.
Electrical location 6" above ground in lower left corner of unit.
Supply hose 70 7/8" with ¼" female compression fitting (standard ice-maker connector).
