Technical Overview
Overall Appliance Dimensions (HxWxD) (in)
83 9/16" x 29 3/4" x 24"
Dimensions (HxWxD)
2123x756x608 mm
Required Cutout Size (HxWxD) (in)
84 x 30 x 24_IN
Required cutout size (HxWxD)
2134x762x610 mm
Highlights
Special Features
Dark brushed stainless steel interior, refined with solid anthracite aluminium elements
Warm white and glare-free LED light concept for optimal food presentation
Spacious freezing compartment with integrated ice maker
Professional freshness system with five different climate zones
Guided interaction via intuitive touch display
Specifications
Solid anthracite aluminium door racks
Cushioned door closing system.
Animated quick guides to assist appliance operation.
Dynamic cold air distribution with Multi-Flow Air System.
Automatic defrosting with defrost water evaporation.
Constant air purification by 2 activated charcoal air filters.
Sabbath mode certified by Star-K.
Open-door and malfunction warning system.
Remote control and monitoring.
Professional freshness system.
No-Frost technology with fast cooling.
Temperature adjustable from +2 °C to +8 °C.
Integrated water dispenser.
2 aluminium-framed safety glass shelves, individually adjustable in height.
1 integrated safety glass shelf.
Optimal food presentation with warm white and glare-free, hidden LED light bars (3000 K).
Flexible positioning of door racks through hidden rail system.
3 door racks, thereof 2 height adjustable.
Total volume of all refrigerator compartments: 10.9 cu. ft.
1 fresh climate drawer with humidity control.
Temperature adjustable from -1 °C to +2 °C.
Ideal storage conditions for different foods through dedicated programmes (e.g. Fruit, Vegetables, Meat).
Individual adjustment of temperature and humidity.
Extended food preservation with ethylene absorber.
Indirect illumination, transparent front.
Fully extendable, with cushioned closing system.
Temperature dependent on cooling compartment (always 2K to 3K lower).
Indirect illumination, transparent front.
Fully extendable, with cushioned closing system.
No-frost technology with fast freezing at -26 °C.
4-star freezer compartment.
Temperature adjustable from -24 °C to -16 °C.
Freezer burn protection.
Oxidation protection.
Freezing capacity 13 kg/24 h.
Storage time after a malfunction 10 h.
Spacious, fully extendable freezer compartment with synchronously running pull-out rails.
2 extendable interior drawers.
Warm-white, glare-free LED lighting (3000 K).
Total volume of freezer compartment: 5.6 cu. ft.
Integrated automatic ice maker in the freezer compartment, with fixed water connection.
Ice maker can be switched off independently.
Active charcoal water filter for water inlet, integrated in ventilation grille area.
Saturation indicator for filter via full touch TFT display
Ice cube production: approx. 5.5 lb/24 h.
Removable ice storage container with approx. 6.6 lb capacity.
Integrated, easy accessible ice cube scoop.
Noise level 39 dB (re 1 pW).
Flat hinge.
Door hinge right, reversible.
Door opening angle of 115°, fixable at 90°.
When rest mode is active, the appliance can only be opened using a handle.
Shut-off valve for water connection must be planned next to the appliance and always be accessible.
If the water pressure exceeds 0.8 MPa (8 bar), connect pressure relief valve between water tap and hose set.
Total rating 1.079 kWh/24h.
Total Amps: 10 A.
Connecting cable 118" (3.0 m), detachable.
Cold water connection required.
Electrical location 6'' above ground in lower left corner of unit.
