Technical Overview
Material body
Stainless steel
Built-in / Free-standing
Built-in
Fan levels
3 power levels and 1 intensive mode
Air output extraction (max)
450 m³/h
Air output extraction (intensive)
640 m³/h
Sound power level extraction (max)
55 dB
Width
60 cm
Specifications
From the inventor of flat kitchen hoods
Especially quiet
Easy filter change
Air extraction or air recirculation system
Exhaust mode DIN EN 61591 : 640 m³ / h
Controls at front.
3 electronically controlled power levels.
Intensive mode.
Grease filter saturation indicator.
Cartridge-type filter, dishwasher-safe.
Compact fluorescent lamp 1 x 36 W.
Light can be switched on separately.
Extendible steam screen 175 mm.
For calculating the exhaust air line go to Rodun online at www.gaggenau.com.
For maximum exhaust air line use Gaggenau flat duct system AD 8… or Naber-System Compair flow. Other flat ducts are not permitted!
When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the power supply line of the ventilation appliance needs a suitable safety switch.
Vario cooktops with intensive production of vapours like VR/VP/VF should be placed in the middle beneath the hood (in this case air recirculation is not recommended).
Clearance above electric appliances min. 47 cm.
To be installed in an upper cabinet without base.
70 cm hood can be installed in 60 cm upper cabinet.
To change the filter, the door of the cabinet must be opened completely.
Total connected load 230 W.
Connecting cable 1.5 m with plug.
