Check appliance compatibility
How to find your E-Number
The model number (E-number) is located on the type plate of your device.
Specifications
Control module of ceiling ventilation without light
For configurations without integrated light
Power levels depend on the remote fan unit, see table on page XX.
7-key infrared remote control, backup keys for operation also on the control module.
3 electronically controlled power levels and 1 intensive mode.
Interval ventilation, 6 min.
Run-on function, 6 min.
Grease filter saturation indicator.
Connection to the respective appliances via network cable.
When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the hood’s power supply line needs a suitable safety switch.
Fixing at the filter module.
Total connected load 355 - 1160 W.
Connecting cable 1.75 m, pluggable.
