Technical Overview
Installation typology
Wall-mounted
Width of appliance
90 cm
Control your hood with your Home Connect hob
Yes
Sound pressure recirculated air level 2
48 dB(A) re 1pW
PerfectAir
Yes
Type of extraction
air extraction / air recirculation
Air output extraction (max)
529 m³/h
Air output extraction (intensive)
990 m³/h
Specifications
Energy-saving, low-noise fan
Air extraction or recirculation system
Performance and noise level, output level 3/Intensive: Air output according to DIN EN 61591. Sound power level according to EN 60704-3. Sound pressure level according to EN
Air extraction: 529 / 990 m³/h. 57 / 70 dB (A) re 1 pW. 44 / 57 dB (A) re 20 μPa.
Air recirculation: 461 / 670 m³/h. 68 / 78 dB (A) re 1 pW. 55 / 65 dB (A) re 20 μPa.
Three electronically controlled power levels and an intensive mode.
Metal grease filter, dishwasher-safe.
Lamp output 2 x 3w LED Light.
Illuminance: 519 lx
Fan technology with highly efficient, brushless DC motor.
Energy consumption 36.7 kWh/year.
Ventilation efficiency class A.
Ilumination efficiency class A.
Grease filter efficiency class B.
Sound level min. 43 dB / max. 57 dB normal mode.
Clearance above gas appliances min. 60 cm (more than total load gas 12 kW min. 70 cm).
Clearance above electric appliances min. 45 cm.
Total connected load 270 W.
Connecting cable 1.3 m with plug.
