Expressive seriesFreezerRVF417190

Vario cooling Expressive series freezer 213.4 x 45.7 cm
RVF417190

New
1 / 6
Photo Nr. 1 of the product RVF417190
Photo Nr. 2 of the product RVF417190
Photo Nr. 3 of the product RVF417190
Photo Nr. 4 of the product RVF417190
Photo Nr. 5 of the product RVF417190
Photo Nr. 6 of the product RVF417190
Photo thumb Nr. 1 of the product RVF417190
Photo thumb Nr. 2 of the product RVF417190
Photo thumb Nr. 3 of the product RVF417190
Photo thumb Nr. 4 of the product RVF417190
Photo thumb Nr. 5 of the product RVF417190
Photo thumb Nr. 6 of the product RVF417190
Photo thumb Nr. 1 of the product RVF417190
Photo thumb Nr. 2 of the product RVF417190
Photo thumb Nr. 3 of the product RVF417190
Photo thumb Nr. 4 of the product RVF417190
Photo thumb Nr. 5 of the product RVF417190
Photo thumb Nr. 6 of the product RVF417190

Vario cooling Expressive series freezer 213.4 x 45.7 cm
RVF417190

Energy label E from G to A
Find a local Dealer

Additional information

Dark brushed stainless steel interior, refined with solid anthracite aluminium elements
Warm white and glare-free LED light concept for optimal food presentation in all compartments
Opening assist for door with two options:
1. Push-to-open function for integration into handleless furniture front
2. Pull-to-open function to facilitate opening the door using a handle
The drawers in the RVC and RVF models are positioned at the same height. With side-by-side installation, the glass shelves and door racks can be aligned on the same level.
Flexible positioning of shelves and door racks through hidden rail system
Flat dark brushed stainless steel inner door
Total volume 280 litres
Opening assist for door.
Cushioned door closing system.
User guidance through light and display response to drawer interaction.
Automatic brightness adjustment based on ambient illumination.
Hidden touch display.
Dynamic cold air distribution.
Automatic defrosting with defrost water evaporation.
Rest mode certified by Star-K.
When rest mode is active, the appliance can only be opened using a handle.
Open-door and malfunction alarm.
Remote control and monitoring.
No-frost technology with fast freezing at -30 °C.
4-star freezer compartment.
Temperature adjustable from -16 °C to -24 °C.
Freezer burn protection.
Oxidation protection.
Freezing capacity 16 kg /24 h.
Storage time after a malfunction 10 h.
Warm-white, glare-free LED lighting (3000 K) within freezer compartment.
3 aluminium-framed safety glass shelves, individually adjustable in height.
Flexible positioning of door racks through hidden rail system.
4 height-adjustable door racks.
3 fully extendable drawers, with cushioned closing system.
Hidden in one drawer for optimised usable space.
With fixed water connection (inlet).
Can be switched off.
Ice cube production: approx. 2.4 kg /24 h.
Removable ice storage container with approx. 2 kg capacity.
Integrated, easy accessible ice cube scoop.
Particle filter for water inlet, integrated in ventilation grille area.
Saturation indicator shown in touch display.
Energy efficiency class E at a range of energy efficiency classes from A to G.
Energy consumption 261 kWh/year.
Noise level 38 dB (A) re 1 pW.
Flat hinge.
Door hinge left, reversible.
Door opening angle of 115°, fixable at 90°.
Max. door panel weight 55 kg.
Shut-off valve for water connection must be planned next to the appliance and always be accessible.
If the water pressure exceeds 0.8 MPa (8 bar), connect pressure relief valve between water tap and hose set.
Total connected load 0.300 KW.
Connecting cable 3.0 m, pluggable.
Water inlet.
Supply hose 1.8 m with 3/4" connection.
Water pressure 2 bar to 8 bar.
